Visoria B Laboratory Microscope
Experience enhanced efficiency and comfort in your daily microscopy routine with the Visoria B laboratory microscope — purpose-built for life science and clinical laboratory applications.
Streamline your workflow with encoded functions, optimized lighting, and thoughtfully designed features. Its ergonomic design keeps you comfortable through long sessions, helping reduce strain so you can focus on what matters most — accurate results.
Technical Advantages
- Used for examining blood, tissue, urine, and other biological specimens to support disease diagnosis, laboratory testing, and medical research.
- Ideal for studying cells, microorganisms, plant tissues, and biological structures in universities, research institutes, and biotechnology laboratories.
- Provides detailed observation of tissue sections and cellular samples for cancer research, pathology, and diagnostic analysis.
- Widely used in hospitals, medical colleges, and teaching laboratories for practical training, routine microscopy, and scientific education.
Technical Specifications
System Specifications
| Specification | Details |
|---|---|
| Microscope Size & Weight | Length: 410 mm, 456 mm (with fluorescence lamphouse), Width: 331 mm, Height: 505 mm, Approx. 18 kg (depending on configuration) |
| Stand | Illumination toggle buttons with status indicator, image capture button, antimicrobial surface with AgTreat according to ISO 22196 |
| Nosepiece | Encoded 6x (M25) |
| Eyepieces (FOV) | 20 / 22 / 25 mm |
| Tubes | Wide range of standard, ergonomic and phototubes with different beam splitters available |
| Digital Version | Digital version with 10" screen / tablet |
| Ergonomic Accessories | Wide range of ergonomic accessories available (ErgoTubes, ErgoLift, ErgoModules) |
| Encoded Illumination Management | IL & TL: High-power white LED, encoded 4-color fluorescence illumination (UV: 375 / 15 nm, Blue: 475 / 30 nm, Green: 546 / 75 nm, Red: 628 / 18 nm), additional external light sources available on request (non-encoded) |
| Fluorescence Light Axis | Optional |
| Incident Light (IL) | Brightfield, Fluorescence, DIC, Qualitative Polarization |
| Transmitted Light Axis | Manual, fixed and flip-top condenser operation with color-coded diaphragm assistant |
| Transmitted Light (TL) | Brightfield, Darkfield, Phase Contrast, DIC, Qualitative Polarization |
| Stage | Manual XY stage with ceramic plate, additional manual XY stages available, supports 1-specimen or 2-specimen holder |
| Stage Control | Left- or right-handed stage operation with torque-adjustable handle |
| Focus Drive | Height-adjustable focus knobs, 19 mm travel range, maximum 28 mm total stage stroke (depending on stage and condenser type), 2-gear (coarse/fine) or 3-gear (coarse/medium/fine) focus drive with torque adjustment and adjustable upper focus stop |
| Analyzer | Fixed, 180° / 360° |
| Polarizer | Fixed and rotatable |
| Supply Voltage | 100–240 V AC, 50 / 60 Hz, Maximum power consumption: 15 W |
| Ambient Conditions | Operating temperature: 15–35°C, Relative humidity: Maximum 80% up to 30°C (non-condensing) |
